Compressor Technical Data

Model: GL45TB       Code: 404010327416

General Data

Refrigerant: R134a
Application: MHBP
Evaporating Temperature Range: -25°C to +10°C
Voltage/Frequency: 220/240V/50 HZ
Compressor Cooling: Fan Cooling
Expansion Device: Capillary / Valve
Packaging Quantity: Multi - 96:120 pcs
Approvals: VDE-CE-GOST

Mechanical Data

Oil Charge: 300 cm3
Oil Type Configuration: ester
Oil Type Viscosity: 19 cSt
Weight: 8 kg

Electrical Data

Motor Type: CSIR
Voltage working range at 50 Hz: 198-264V
Maximum Motor Temperature: 130°C
Locked Rotor Current: 6.5 A
Start Winding Resistance: 49.86 Ω at 25°C
Run Winding Resistance: 19.27 Ω at 25°C
Phase: 1 ph

External Characteristics

Internal Diameter (mm)
Suction Connector 6.5
Discharge Connector 4.9
Process Connector 6.5
Material Copper

Electrical Components

Starting Device: RELAY MTRP26
Motor Protection: T0068/xx
Owl Image

Assembly instructions for Terminal board

Download

External View

Download
